Intelligent Closestool PCBA
  • Intelligent Closestool PCBAIntelligent Closestool PCBA
  • Intelligent Closestool PCBAIntelligent Closestool PCBA
  • Intelligent Closestool PCBAIntelligent Closestool PCBA
  • Intelligent Closestool PCBAIntelligent Closestool PCBA
  • Intelligent Closestool PCBAIntelligent Closestool PCBA

Intelligent Closestool PCBA

For more than a decade, Unixplore Electronics has focused on providing comprehensive turnkey solutions for high-quality intelligent Closestool PCBA in China. We have ISO9001:2015 and PCB assembly standard IPC-610E certifications, ensuring the quality of Our products.

Send Inquiry

Product Description

How to design Intelligent Closestool PCBA controller ?

At Unixplore Electronics, we are dedicated to providing high-quality Intelligent Closestool PCBA and ensuring that our customers are fully informed about its functions and features.
We encourage both new and existing customers to partner with us and work towards a brighter future together.

Intelligent Closestool PCBA controller is one of the core components of the smart toilet. It is mainly used to control the functions of the toilet, such as heating, warm water rinse, warm wind drying. it is generally made in water-proof and leakage-proof design, and has multiple functions, such as temperature control, time control, functional control, etc.

Its design needs to consider power supply, circuit protection, signal processing, keys, display, waterproof, appearance and other aspects.
In terms of power design, a stable switching power supply needs to be used for stepdown treatment to ensure the stability and safety of the power supply.
In terms of circuit protection, it is necessary to consider overcurrent protection, overvoltage protection, and under voltage protection to ensure the safety and stability of the circuit.
In terms of signal processing, signal isolation is needed to avoid signal interference and instability. In terms of keys and display, it is necessary to consider comfort and ease of use. Generally, light-touch buttons or inductive buttons and LED digital display or LCD screens are used.
In terms of waterproof, waterproof materials are needed or waterproof treatment to avoid short circuit or damage to the PCB control board.
In terms of appearance design, it is necessary to consider the beauty and fashion, and generally use a simple and stylish style for design.

Unixplore provides one-stop turnkey service for your EMS project. Feel free to contact us for your board building, we can make a quotation in 24 hours after we receive your Gerber file and BOM list!

Intelligent Closestool PCBA Manufacture

* Gerber file and BOM list supplied by client
* Blank PCB made, components purchased by us
* PCB fabrication with parts fully assembled
* 100% Function Tested OK before shipping
* RoHS compliant, Lead-free manufacturing process
* Quick delivery, with independent ESD package
* One stop electronic manufacturing service for PCB design, PCB layout, PCB manufacture, components procurement, PCB SMT and DIP assembly, IC programming, function test, packaging and delivery

Unixplore PCB & PCB Assembly Capability

Parameter Capability
Layers 1-40 layers
Assembly Type Through-Hole (THT), Surface Mount (SMT), Mixed (THT+SMT)
Minimum Component Size 0201(01005 Metric)
Maximum Component Size 2.0 in x 2.0 in x 0.4 in (50 mm x 50 mm x 10 mm)
Component Package Types BGA, FBGA, QFN, QFP, VQFN, SOIC, SOP, SSOP, TSSOP, PLCC, DIP, SIP, etc.
Minimum Pad Pitch 0.5 mm (20 mil) for QFP, QFN, 0.8 mm (32 mil) for BGA
Minimum Trace Width 0.10 mm (4 mil)
Minimum Trace Clearance 0.10 mm (4 mil)
Minimum Drill Size 0.15 mm (6 mil)
Maximum Board Size 18 in x 24 in (457 mm x 610 mm)
Board Thickness 0.0078 in (0.2 mm) to 0.236 in (6 mm)
Board Material CEM-3,FR-2,FR-4, High-Tg, HDI, Aluminum, High Frequency, FPC, Rigid-Flex, Rogers, etc.
Surface Finish OSP, HASL, Flash Gold, ENIG, Gold Finger, etc.
Solder Paste Type Leaded or Lead-Free
Copper Thickness 0.5OZ – 5 OZ
Assembly Process Reflow Soldering, Wave Soldering, Manual Soldering
Inspection Methods Automated Optical Inspection (AOI), X-ray, Visual Inspection
Testing Methods In-House Functional Test, Probe Test, Aging Test, High and Low Temperature Test
Turnaround Time Sampling: 24 hours to 7 days, Mass Run: 10 - 30 days
PCB Assembly Standards ISO9001:2015; ROHS, UL 94V0, IPC-610E class ll

Unixplore Value-Added EMS Service

● IC pre-programming service with file in format of HEX,ELF and BIN.
● Intelligent closestool PCBA Function test fixture customized according to client’s test requirements
● Box building service including plastic & metal case mold and part production
● Conformal coating including selective lacquer coating, epoxy resin potting
● Wire harness and cable assembly
● Finished product assembly including box, screen, membrane switch, labelling and customized carton or retail box packing.
● Various third-party tests for PCBA are available upon request
● Product Certification Assistance

PCBA Production Procedure

  • 1. Automatic solderpaste printing

  • 2. solderpaste printing done

  • 3. SMT pick and place

  • 4. SMT pick and place done

  • 5. ready for reflow soldering

  • 6. reflow soldering done

  • 7. ready for AOI

  • 8. AOI inspection process

  • 9. THT component placement

  • 10. wave soldering process

  • 11. THT assembly done

  • 12. AOI Inspection for THT assembly

  • 13. IC programming

  • 14. function test

  • 15. QC Check and Repair

  • 16. PCBA conformal coating Process

  • 17. ESD packing

  • 18. Ready for Shipping



For Finished Product
