Servo Motor PCBA
  • Servo Motor PCBAServo Motor PCBA
  • Servo Motor PCBAServo Motor PCBA
  • Servo Motor PCBAServo Motor PCBA

Servo Motor PCBA

Unixplore Electronics specializes in one-stop turnkey manufacture and supply for Servo Motor PCBA in China since 2008 with certification of ISO9001:2015 and PCB assembly standard IPC-610E,which is widely used in various industrial control equipments and automation systems.


Send Inquiry

Product Description

What is Servo Motor PCBA?

UNIXPLORE Electronics is proud to offer you Servo Motor PCBA. Our goal is to ensure that our customers are fully aware of our products and their functionality and features. We sincerely invite new and old customers to cooperate with us and move towards a prosperous future together.

Servo motor PCBA refers to the Printed Circuit Board Assembly part used to drive servo motors, including circuit boards and components, and is one of the core parts of the servo motor driver. Servo motor is a motor that can accurately control motion parameters such as position, speed, and torque. It is widely used in fields such as robots, printing equipment, and automation equipment. It requires a high-precision and stable control system to drive it.

The servo motor PCBA controls the movement of the motor by adjusting the motor control signal to achieve precise control of motion parameters such as position, speed, and torque. Its main functions are as follows:

Power management: Control the power supply of the servo motor and stabilize the power supply to ensure the normal operation of the motor driver.

Signal processing: Read signals from the servo motor's encoder and position feedback sensor and process them to ensure accurate control of the motor.

Control logic: According to the input instructions and control parameters, the precise positioning, speed and torque control of the motor are realized through control logic.

Protection function: Protect the motor driver and the motor itself to prevent damage to the motor such as overload, overcurrent, overvoltage, etc.

Data communication: Transmit the position, speed, torque and other motion parameters of the servo motor to other devices or control systems through the communication interface.

Servo motor drive PCBA has the advantages of high performance, high precision, fast speed, and high stability, and plays an important role in the drive and control of servo motors. It is necessary to select the appropriate servo motor drive PCBA according to the specific application requirements to meet the stability and accuracy requirements of the control system.

UNIXPLORE provides one-stop TURN-KEY service for your EMS project. Feel free to contact us for your board building, we can make a quotation in 24 hours after we receive your Gerber file and BOM list!

Servo Motor PCBA Manufacture

* Gerber file and BOM list supplied by client
* Blank PCB made, components purchased by us
* PCB fabrication with parts fully assembled
* 100% Function Tested OK before shipping
* RoHS compliant, Lead-free manufacturing process
* Quick delivery, with independent ESD package
* One stop electronic manufacturing service for PCB design, PCB layout, PCB manufacture, components procurement, PCB SMT and DIP assembly, IC programming, function test, packaging and delivery

Unixplore PCB & PCB Assembly Capability

Parameter Capability
Layers 1-40 layers
Assembly Type Through-Hole (THT), Surface Mount (SMT), Mixed (THT+SMT)
Minimum Component Size 0201(01005 Metric)
Maximum Component Size 2.0 in x 2.0 in x 0.4 in (50 mm x 50 mm x 10 mm)
Component Package Types BGA, FBGA, QFN, QFP, VQFN, SOIC, SOP, SSOP, TSSOP, PLCC, DIP, SIP, etc.
Minimum Pad Pitch 0.5 mm (20 mil) for QFP, QFN, 0.8 mm (32 mil) for BGA
Minimum Trace Width 0.10 mm (4 mil)
Minimum Trace Clearance 0.10 mm (4 mil)
Minimum Drill Size 0.15 mm (6 mil)
Maximum Board Size 18 in x 24 in (457 mm x 610 mm)
Board Thickness 0.0078 in (0.2 mm) to 0.236 in (6 mm)
Board Material CEM-3,FR-2,FR-4, High-Tg, HDI, Aluminum, High Frequency, FPC, Rigid-Flex, Rogers, etc.
Surface Finish OSP, HASL, Flash Gold, ENIG, Gold Finger, etc.
Solder Paste Type Leaded or Lead-Free
Copper Thickness 0.5OZ – 5 OZ
Assembly Process Reflow Soldering, Wave Soldering, Manual Soldering
Inspection Methods Automated Optical Inspection (AOI), X-ray, Visual Inspection
Testing Methods In-House Functional Test, Probe Test, Aging Test, High and Low Temperature Test
Turnaround Time Sampling: 24 hours to 7 days, Mass Run: 10 - 30 days
PCB Assembly Standards ISO9001:2015; ROHS, UL 94V0, IPC-610E class ll

Unixplore Value-Added EMS Service

● IC pre-programming service with file in format of HEX,ELF and BIN.
● Servo Motor PCBA Function test fixture customized according to client’s test requirements
● Box building service including plastic & metal case mold and part production
● Conformal coating including selective lacquer coating, epoxy resin potting
● Wire harness and cable assembly
● Finished product assembly including box, screen, membrane switch, labelling and customized carton or retail box packing.
● Various third-party tests for PCBA are available upon request
● Product Certification Assistance

PCBA Production Procedure

  • Servo Motor PCBA

    1. Automatic solderpaste printing

  • Servo Motor PCBA

    2. solderpaste printing done

  • Servo Motor PCBA

    3. SMT pick and place

  • Servo Motor PCBA

    4. SMT pick and place done

  • Servo Motor PCBA

    5. ready for reflow soldering

  • Servo Motor PCBA

    6. reflow soldering done

  • Servo Motor PCBA

    7. ready for AOI

  • Servo Motor PCBA

    8. AOI inspection process

  • Servo Motor PCBA

    9. THT component placement

  • Servo Motor PCBA

    10. wave soldering process

  • Servo Motor PCBA

    11. THT assembly done

  • Servo Motor PCBA

    12. AOI Inspection for THT assembly

  • Servo Motor PCBA

    13. IC programming

  • Servo Motor PCBA

    14. function test

  • Servo Motor PCBA

    15. QC Check and Repair

  • Servo Motor PCBA

    16. PCBA conformal coating Process

  • Servo Motor PCBA

    17. ESD packing

  • Servo Motor PCBA

    18. Ready for Shipping



Servo Motor PCBA
Servo Motor PCBA
For Finished Product

Servo Motor PCBA
Servo Motor PCBA
