Unixplore Electronics specializes in one-stop turnkey manufacture and supply for pressure sensor PCBA in China since 2008 with certification of ISO9001:2015 and PCB assembly standard IPC-610E,which is widely used in various industrial control equipments and automation systems.


Send Inquiry

Product Description

What is pressure sensor PCBA?

UNIXPLORE Electronics is proud to offer you pressure sensor PCBA. Our goal is to ensure that our customers are fully aware of our products and their functionality and features. We sincerely invite new and old customers to cooperate with us and move towards a prosperous future together.

Pressure sensor PCBA refers to the Printed Circuit Board Assembly part used in pressure sensors and is one of the core parts of the pressure sensor. The pressure sensor PCBA senses the measured pressure value through sensor devices such as pressure sensors, uses an A/D conversion circuit to convert it into an analog electrical signal, and then further processes it through the control chip, and converts the power information into output signals such as voltage and current for subsequent use. data analysis and management.

The main functions of the pressure sensor PCBA are as follows:

Sensing signal collection: Convert the sensed pressure signal into an analog electrical signal.

Signal amplification: Process the collected signal to denoise and convert it to a higher voltage value for more accurate A/D digital conversion.

Digital signal processing: Using technologies such as high-speed A/D conversion and digital signal processor (DSP) to convert analog signals into digital signals, signal processing and algorithm calculations are performed on the internal embedded processor.

Communication module: Through various communication protocols and interfaces such as serial port, Bluetooth, Wi-Fi, Zigbee or Modbus, it can be connected to the electrical control system, data collection system or intelligent equipment for remote monitoring and management.

Power management: Manage the power supply of sensors to ensure the stability and continuous operation of the sensor system.

As the core part of the pressure sensor, the pressure sensor PCBA has the characteristics of high precision, high reliability, and high stability. It can read and process various pressure signals and can be widely used in industrial control, medical equipment, automobiles, environmental protection and other fields. To help achieve greater product performance and higher quality control.

UNIXPLORE provides one-stop TURN-KEY service for your EMS project. Feel free to contact us for your board building, we can make a quotation in 24 hours after we receive your Gerber file and BOM list!

Pressure sensor PCBA Manufacture

* Gerber file and BOM list supplied by client
* Blank PCB made, components purchased by us
* PCB fabrication with parts fully assembled
* 100% Function Tested OK before shipping
* RoHS compliant, Lead-free manufacturing process
* Quick delivery, with independent ESD package
* One stop electronic manufacturing service for PCB design, PCB layout, PCB manufacture, components procurement, PCB SMT and DIP assembly, IC programming, function test, packaging and delivery

Unixplore PCB & PCB Assembly Capability

Parameter Capability
Layers 1-40 layers
Assembly Type Through-Hole (THT), Surface Mount (SMT), Mixed (THT+SMT)
Minimum Component Size 0201(01005 Metric)
Maximum Component Size 2.0 in x 2.0 in x 0.4 in (50 mm x 50 mm x 10 mm)
Component Package Types BGA, FBGA, QFN, QFP, VQFN, SOIC, SOP, SSOP, TSSOP, PLCC, DIP, SIP, etc.
Minimum Pad Pitch 0.5 mm (20 mil) for QFP, QFN, 0.8 mm (32 mil) for BGA
Minimum Trace Width 0.10 mm (4 mil)
Minimum Trace Clearance 0.10 mm (4 mil)
Minimum Drill Size 0.15 mm (6 mil)
Maximum Board Size 18 in x 24 in (457 mm x 610 mm)
Board Thickness 0.0078 in (0.2 mm) to 0.236 in (6 mm)
Board Material CEM-3,FR-2,FR-4, High-Tg, HDI, Aluminum, High Frequency, FPC, Rigid-Flex, Rogers, etc.
Surface Finish OSP, HASL, Flash Gold, ENIG, Gold Finger, etc.
Solder Paste Type Leaded or Lead-Free
Copper Thickness 0.5OZ – 5 OZ
Assembly Process Reflow Soldering, Wave Soldering, Manual Soldering
Inspection Methods Automated Optical Inspection (AOI), X-ray, Visual Inspection
Testing Methods In-House Functional Test, Probe Test, Aging Test, High and Low Temperature Test
Turnaround Time Sampling: 24 hours to 7 days, Mass Run: 10 - 30 days
PCB Assembly Standards ISO9001:2015; ROHS, UL 94V0, IPC-610E class ll

Unixplore Value-Added EMS Service

● IC pre-programming service with file in format of HEX,ELF and BIN.
● Pressure sensor PCBA Function test fixture customized according to client’s test requirements
● Box building service including plastic & metal case mold and part production
● Conformal coating including selective lacquer coating, epoxy resin potting
● Wire harness and cable assembly
● Finished product assembly including box, screen, membrane switch, labelling and customized carton or retail box packing.
● Various third-party tests for PCBA are available upon request
● Product Certification Assistance

PCBA Production Procedure

  • pressure sensor PCBA

    1. Automatic solderpaste printing

  • pressure sensor PCBA

    2. solderpaste printing done

  • pressure sensor PCBA

    3. SMT pick and place

  • pressure sensor PCBA

    4. SMT pick and place done

  • pressure sensor PCBA

    5. ready for reflow soldering

  • pressure sensor PCBA

    6. reflow soldering done

  • pressure sensor PCBA

    7. ready for AOI

  • pressure sensor PCBA

    8. AOI inspection process

  • pressure sensor PCBA

    9. THT component placement

  • pressure sensor PCBA

    10. wave soldering process

  • pressure sensor PCBA

    11. THT assembly done

  • pressure sensor PCBA

    12. AOI Inspection for THT assembly

  • pressure sensor PCBA

    13. IC programming

  • pressure sensor PCBA

    14. function test

  • pressure sensor PCBA

    15. QC Check and Repair

  • pressure sensor PCBA

    16. PCBA conformal coating Process

  • pressure sensor PCBA

    17. ESD packing

  • pressure sensor PCBA

    18. Ready for Shipping



pressure sensor PCBA
pressure sensor PCBA
For Finished Product

pressure sensor PCBA
pressure sensor PCBA
