ISA Card PCBA
  • ISA Card PCBAISA Card PCBA
  • ISA Card PCBAISA Card PCBA
  • ISA Card PCBAISA Card PCBA

ISA Card PCBA

Unixplore Electronics specializes in one-stop turnkey manufacture and supply for ISA card PCBA in China since 2008 with certification of ISO9001:2015 and PCB assembly standard IPC-610E,which is widely used in various industrial control equipments and automation systems.

Model:UE-172

Send Inquiry

Product Description


How to choose a reliable ISA Card PCBA manufacturer?

Unixplore Electronics is proud to offer you ISA Card PCBA. Our goal is to ensure that our customers are fully aware of our products and their functionality and features. We sincerely invite new and old customers to cooperate with us and move towards a prosperous future together.


An ISA (Industry Standard Architecture) card is an expansion card used in early IBM-compatible computers to provide additional functionality. These cards were introduced in 1981 and were the primary means of expanding a computer's capabilities until they were replaced by newer technologies such as PCI and AGP. ISA cards were typically used for adding features such as sound cards, modems, and network cards. They were typically inserted into an ISA slot on the motherboard of the computer, and were often characterized by their long, rectangular shape.


When choosing a reliable ISA card PCBA (Printed Circuit Board Assembly) factory, there are several factors to consider. Here are a few key things to keep in mind:


Experience: Look for a factory that has a good track record of producing high quality ISA card PCBAs. Check their website and read reviews to see what other customers have experienced.


Equipment & Technology: Make sure the factory has the right equipment and technology to produce your ISA card PCBA. They should have the latest software, machines and materials to ensure the highest quality results.


Certifications: Check if the PCBA factory has relevant certifications. For instance, ISO 9001 or Other Quality Management Systems Certifications show that the factory has put in place quality management processes, which can lead to better quality control of the PCBAs.


Customer Service: A reliable factory should have a dedicated customer service team that can provide you with fast and helpful responses to all your queries.


Cost: Compare costs at different factories to ensure you receive the best value for your money. Make sure that you are able to receive a quote that covers everything needed, including components cost, assembly cost and shipping cost.


Once you have gathered the above details, you'll have a better understanding of what the ISA card PCBA factory is capable of delivering, including their cost, reliability and quality.


Unixplore provides one-stop TURN-KEY service for your EMS project. Feel free to contact us for your board building, we can make a quotation in 24 hours after we receive your Gerber file and BOM list!

ISA Card PCBA Manufacture

* Gerber file and BOM list supplied by client
* Blank PCB made, components purchased by us
* PCB fabrication with parts fully assembled
* 100% Function Tested OK before shipping
* RoHS compliant, Lead-free manufacturing process
* Quick delivery, with independent ESD package
* One stop electronic manufacturing service for PCB design, PCB layout, PCB manufacture, components procurement, PCB SMT and DIP assembly, IC programming, function test, packaging and delivery

Unixplore PCB & PCB Assembly Capability

Parameter Capability
Layers 1-40 layers
Assembly Type Through-Hole (THT), Surface Mount (SMT), Mixed (THT+SMT)
Minimum Component Size 0201(01005 Metric)
Maximum Component Size 2.0 in x 2.0 in x 0.4 in (50 mm x 50 mm x 10 mm)
Component Package Types BGA, FBGA, QFN, QFP, VQFN, SOIC, SOP, SSOP, TSSOP, PLCC, DIP, SIP, etc.
Minimum Pad Pitch 0.5 mm (20 mil) for QFP, QFN, 0.8 mm (32 mil) for BGA
Minimum Trace Width 0.10 mm (4 mil)
Minimum Trace Clearance 0.10 mm (4 mil)
Minimum Drill Size 0.15 mm (6 mil)
Maximum Board Size 18 in x 24 in (457 mm x 610 mm)
Board Thickness 0.0078 in (0.2 mm) to 0.236 in (6 mm)
Board Material CEM-3,FR-2,FR-4, High-Tg, HDI, Aluminum, High Frequency, FPC, Rigid-Flex, Rogers, etc.
Surface Finish OSP, HASL, Flash Gold, ENIG, Gold Finger, etc.
Solder Paste Type Leaded or Lead-Free
Copper Thickness 0.5OZ – 5 OZ
Assembly Process Reflow Soldering, Wave Soldering, Manual Soldering
Inspection Methods Automated Optical Inspection (AOI), X-ray, Visual Inspection
Testing Methods In-House Functional Test, Probe Test, Aging Test, High and Low Temperature Test
Turnaround Time Sampling: 24 hours to 7 days, Mass Run: 10 - 30 days
PCB Assembly Standards ISO9001:2015; ROHS, UL 94V0, IPC-610E class ll

Unixplore Value-Added EMS Service

● IC pre-programming service with file in format of HEX,ELF and BIN.
● ISA Card PCBA Function test fixture customized according to client’s test requirements
● Box building service including plastic & metal case mold and part production
● Conformal coating including selective lacquer coating, epoxy resin potting
● Wire harness and cable assembly
● Finished product assembly including box, screen, membrane switch, labelling and customized carton or retail box packing.
● Various third-party tests for PCBA are available upon request
● Product Certification Assistance

PCBA Production Procedure

  • ISA Card PCBA

    1. Automatic solderpaste printing

  • ISA Card PCBA

    2. solderpaste printing done

  • ISA Card PCBA

    3. SMT pick and place

  • ISA Card PCBA

    4. SMT pick and place done

  • ISA Card PCBA

    5. ready for reflow soldering

  • ISA Card PCBA

    6. reflow soldering done

  • ISA Card PCBA

    7. ready for AOI

  • ISA Card PCBA

    8. AOI inspection process

  • ISA Card PCBA

    9. THT component placement

  • ISA Card PCBA

    10. wave soldering process

  • ISA Card PCBA

    11. THT assembly done

  • ISA Card PCBA

    12. AOI Inspection for THT assembly

  • ISA Card PCBA

    13. IC programming

  • ISA Card PCBA

    14. function test

  • ISA Card PCBA

    15. QC Check and Repair

  • ISA Card PCBA

    16. PCBA conformal coating Process

  • ISA Card PCBA

    17. ESD packing

  • ISA Card PCBA

    18. Ready for Shipping


Packaging

For PCBA

ISA Card PCBA
ISA Card PCBA
For Finished Product

ISA Card PCBA
ISA Card PCBA

Hot Tags: ISA Card PCBA, China, Manufacturers, Suppliers, Factory, Customized, Cheap, Quality, Advanced, CE, 1 Year Warranty, Price

Related Category

Send Inquiry

Please Feel free to give your inquiry in the form below. We will reply you in 24 hours.
