Blood Pressure Monitor PCBA

Product Description

How to design blood pressure monitor PCBA control board?

The following is the introduction of high quality blood pressure monitor PCBA, hoping to help you better understand how to design it. Welcome new and old customers to continue to cooperate with Unixplore Electronics to create a better future!

The blood pressure meter circuit board is the core part of the blood pressure meter. It usually includes sensors, signal processing circuits, display screens and power supply.

The sensor part is mainly responsible for perceiving the changes in blood pressure and transforming these changes into electrical signal output.

The signal processing circuit enlarges, filters, and digitalizes the electrical signal output by the sensor to facilitate subsequent display and storage.

The display screen displays the value and waveform of the blood pressure, which is convenient for users to view.

The power supply provides a working power supply for the entire blood pressure monitor, which is usually a battery or AC power supply.

The design of the blood pressure monitor circuit board needs to consider the following aspects:

Accuracy and stability: The blood pressure meter needs to accurately measure blood pressure. Therefore, the design of the circuit board needs to ensure the accuracy and stability of the sensor, and the accuracy and stability of the signal processing circuit.
Power consumption and battery life: Blood pressure monitors need to be used for a long time. Therefore, the design of the circuit board needs to consider power consumption and battery life. Choose low -power devices and circuit design to improve the battery life.
Easy to produce and maintain: The design needs to consider the factors that are easy to produce and maintain, such as the selection of device, the layout and structure of the circuit board, which will directly affect production efficiency and maintenance costs.
Appearance design: The design of the blood pressure meter circuit board also needs to consider the design, including the size, shape, color of the circuit board, to meet the needs of users and aesthetics.
Unixplore provides one-stop turnkey service for your EMS project. Feel free to contact us for your board building, we can make a quotation in 24 hours after we receive your Gerber file and BOM list!

Blood Pressure Monitor PCBA Manufacture

* Gerber file and BOM list supplied by client
* Blank PCB made, components purchased by us
* PCB fabrication with parts fully assembled
* 100% Function Tested OK before shipping
* RoHS compliant, Lead-free manufacturing process
* Quick delivery, with independent ESD package
* One stop electronic manufacturing service for PCB design, PCB layout, PCB manufacture, components procurement, PCB SMT and DIP assembly, IC programming, function test, packaging and delivery

Unixplore PCB & PCB Assembly Capability

Parameter	Capability
Layers	1-40 layers
Assembly Type	Through-Hole (THT), Surface Mount (SMT), Mixed (THT+SMT)
Minimum Component Size	0201(01005 Metric)
Maximum Component Size	2.0 in x 2.0 in x 0.4 in (50 mm x 50 mm x 10 mm)
Component Package Types	BGA, FBGA, QFN, QFP, VQFN, SOIC, SOP, SSOP, TSSOP, PLCC, DIP, SIP, etc.
Minimum Pad Pitch	0.5 mm (20 mil) for QFP, QFN, 0.8 mm (32 mil) for BGA
Minimum Trace Width	0.10 mm (4 mil)
Minimum Trace Clearance	0.10 mm (4 mil)
Minimum Drill Size	0.15 mm (6 mil)
Maximum Board Size	18 in x 24 in (457 mm x 610 mm)
Board Thickness	0.0078 in (0.2 mm) to 0.236 in (6 mm)
Board Material	CEM-3,FR-2,FR-4, High-Tg, HDI, Aluminum, High Frequency, FPC, Rigid-Flex, Rogers, etc.
Surface Finish	OSP, HASL, Flash Gold, ENIG, Gold Finger, etc.
Solder Paste Type	Leaded or Lead-Free
Copper Thickness	0.5OZ – 5 OZ
Assembly Process	Reflow Soldering, Wave Soldering, Manual Soldering
Inspection Methods	Automated Optical Inspection (AOI), X-ray, Visual Inspection
Testing Methods In-House	Functional Test, Probe Test, Aging Test, High and Low Temperature Test
Turnaround Time	Sampling: 24 hours to 7 days, Mass Run: 10 - 30 days
PCB Assembly Standards	ISO9001:2015; ROHS, UL 94V0, IPC-610E class ll

Unixplore Value-Added EMS Service

● IC pre-programming service with file in format of HEX,ELF and BIN.
● Blood Pressure Monitor PCBA Function test fixture customized according to client’s test requirements
● Box building service including plastic & metal case mold and part production
● Conformal coating including selective lacquer coating, epoxy resin potting
● Wire harness and cable assembly
● Finished product assembly including box, screen, membrane switch, labelling and customized carton or retail box packing.
● Various third-party tests for PCBA are available upon request
● Product Certification Assistance
