Drone PCBA

Product Description

How to find a good supplier for your Drone PCBA control board?

Unixplore Electronics is your preferred source for a wide range of Chinese-made commercial drone PCBA. Their products are competitively priced and come with excellent after-sales service. Furthermore, they are very interested in establishing mutually beneficial partnerships.

The drone PCB control board is the core component for the control of the drone. On the drone control board, parameters such as mission, adjusting flight speed, height, and direction can be set, and data returned by the drone can be received in real time, such as the flight status and the shooting screen.

It is generally divided into two types: flying control and navigation control. The flying control PCB is the core component of the drone. It is responsible for controlling the flying posture and motion trajectory of the drone to achieve stable and reliable flight. The navigation control is responsible for planning the flying path and airpoint of drones to achieve independent navigation and path planning.

Usually the drone PCBA will use modular design, which can easily replace and upgrade. At the same time, it also has a variety of interfaces, which can connect various sensors, cameras, GPS and other external devices to achieve more versatile functions and applications.

We need to consider following factors as below when it comes to the component selection of the drone control board:

Performance targets: According to the function and performance requirements of drones, choose components that meet the requirements.
Environmental adaptability: Consider the working temperature, humidity, anti -interference ability and other environmental adaptability of components.
Reliability: Select components with long life and good stability to ensure the safe and stable operation of drones.
Cost: On the premise of satisfying performance and reliability, select a reasonable cost component.
Supply capacity: Considering the supply channels and supply turnaround of components to ensure the production and delivery of drones.

Unixplore provides one-stop turnkey service for your EMS project. Feel free to contact us for your board building, we can make a quotation in 24 hours after we receive your Gerber file and BOM list!

Drone PCBA Manufacture

* Gerber file and BOM list supplied by client
* Blank PCB made, components purchased by us
* PCB fabrication with parts fully assembled
* 100% Function Tested OK before shipping
* RoHS compliant, Lead-free manufacturing process
* Quick delivery, with independent ESD package
* One stop electronic manufacturing service for PCB design, PCB layout, PCB manufacture, components procurement, PCB SMT and DIP assembly, IC programming, function test, packaging and delivery

Unixplore PCB & PCB Assembly Capability

Parameter	Capability
Layers	1-40 layers
Assembly Type	Through-Hole (THT), Surface Mount (SMT), Mixed (THT+SMT)
Minimum Component Size	0201(01005 Metric)
Maximum Component Size	2.0 in x 2.0 in x 0.4 in (50 mm x 50 mm x 10 mm)
Component Package Types	BGA, FBGA, QFN, QFP, VQFN, SOIC, SOP, SSOP, TSSOP, PLCC, DIP, SIP, etc.
Minimum Pad Pitch	0.5 mm (20 mil) for QFP, QFN, 0.8 mm (32 mil) for BGA
Minimum Trace Width	0.10 mm (4 mil)
Minimum Trace Clearance	0.10 mm (4 mil)
Minimum Drill Size	0.15 mm (6 mil)
Maximum Board Size	18 in x 24 in (457 mm x 610 mm)
Board Thickness	0.0078 in (0.2 mm) to 0.236 in (6 mm)
Board Material	CEM-3,FR-2,FR-4, High-Tg, HDI, Aluminum, High Frequency, FPC, Rigid-Flex, Rogers, etc.
Surface Finish	OSP, HASL, Flash Gold, ENIG, Gold Finger, etc.
Solder Paste Type	Leaded or Lead-Free
Copper Thickness	0.5OZ – 5 OZ
Assembly Process	Reflow Soldering, Wave Soldering, Manual Soldering
Inspection Methods	Automated Optical Inspection (AOI), X-ray, Visual Inspection
Testing Methods In-House	Functional Test, Probe Test, Aging Test, High and Low Temperature Test
Turnaround Time	Sampling: 24 hours to 7 days, Mass Run: 10 - 30 days
PCB Assembly Standards	ISO9001:2015; ROHS, UL 94V0, IPC-610E class ll

Unixplore Value-Added EMS Service

● IC pre-programming service with file in format of HEX,ELF and BIN.
● Drone PCBA Function test fixture customized according to client’s test requirements
● Box building service including plastic & metal case mold and part production
● Conformal coating including selective lacquer coating, epoxy resin potting
● Wire harness and cable assembly
● Finished product assembly including box, screen, membrane switch, labelling and customized carton or retail box packing.
● Various third-party tests for PCBA are available upon request
● Product Certification Assistance
