Unixplore Electronics specializes in one-stop turnkey manufacture and supply for high quality BEC PCBA in China since 2008 with quality certification of ISO9001:2015 and PCB assembly standard IPC-610E.

Model:UE-168

Send Inquiry

Product Description

What is BEC PCBA?

As a professional manufacturer, UNIXPLORE Electronics would like to provide you high quality BEC PCBA, together with the best after-sale service and timely delivery.


BEC(Battery Eliminator Circuit) PCBA is designed to provide a stable and continuous power source for your device. BEC PCBA eliminates the need for batteries, providing a cost-effective and environmentally friendly solution. BEC PCBA can be easily integrated into your existing device design, making it the perfect solution for various applications.


Usually Battery Eliminator Circuit PCBA is equipped with an over-voltage protection system, ensuring that your device is protected from any sudden surges in voltage. BEC PCBA also features a built-in thermal protection system, which monitors the temperature of the circuit and adjusts the power supply accordingly.


This PCBA is versatile and can work with a wide range of devices, including but not limited to LED lights, electronic toys, and remote-control cars. With BEC PCBA, you can rest assured that your device will never run out of power!


UNIXPLORE provides one-stop Turn-Key service for your EMS project. Feel free to contact us for your board building, we can make a quotation in 24 hours after we receive your Gerber file and BOM list!


BEC PCBA Manufacture

* PCB file and parts list supplied by client
* Blank PCB made, components purchased by us
* PCB fabrication with parts fully assembled
* 100% Function Tested OK before shipping
* RoHS compliant, Lead-free manufacturing process
* Quick delivery, with independent ESD package
* One stop electronic manufacturing service for PCB design, PCB layout, PCB manufacture, components procurement, PCB SMT and DIP assembly, IC programming, function test, packaging and delivery

Unixplore PCB & PCB Assembly Capability

Parameter Capability
Layers 1-40 layers
Assembly Type Through-Hole (THT), Surface Mount (SMT), Mixed (THT+SMT)
Minimum Component Size 0201(01005 Metric)
Maximum Component Size 2.0 in x 2.0 in x 0.4 in (50 mm x 50 mm x 10 mm)
Component Package Types BGA, FBGA, QFN, QFP, VQFN, SOIC, SOP, SSOP, TSSOP, PLCC, DIP, SIP, etc.
Minimum Pad Pitch 0.5 mm (20 mil) for QFP, QFN, 0.8 mm (32 mil) for BGA
Minimum Trace Width 0.10 mm (4 mil)
Minimum Trace Clearance 0.10 mm (4 mil)
Minimum Drill Size 0.15 mm (6 mil)
Maximum Board Size 18 in x 24 in (457 mm x 610 mm)
Board Thickness 0.0078 in (0.2 mm) to 0.236 in (6 mm)
Board Material CEM-3,FR-2,FR-4, High-Tg, HDI, Aluminum, High Frequency, FPC, Rigid-Flex, Rogers, etc.
Surface Finish OSP, HASL, Flash Gold, ENIG, Gold Finger, etc.
Solder Paste Type Leaded or Lead-Free
Copper Thickness 0.5OZ – 5 OZ
Assembly Process Reflow Soldering, Wave Soldering, Manual Soldering
Inspection Methods Automated Optical Inspection (AOI), X-ray, Visual Inspection
Testing Methods In-House Functional Test, Probe Test, Aging Test, High and Low Temperature Test
Turnaround Time Sampling: 24 hours to 7 days, Mass Run: 10 - 30 days
PCB Assembly Standards ISO9001:2015; ROHS, UL 94V0, IPC-610E class ll

Unixplore Value-Added EMS Service

● IC pre-programming service with file in format of HEX,ELF and BIN.
● BEC PCBA Function test fixture customized according to client’s test requirements
● Box building service including plastic & metal case mold and part production
● Conformal coating including selective lacquer coating, epoxy resin potting
● Wire harness and cable assembly
● Finished product assembly including box, screen, membrane switch, labelling and customized carton or retail box packing.
● Various third-party tests for PCBA are available upon request
● Product Certification Assistance
