LED Flashlight PCBA
  • LED Flashlight PCBALED Flashlight PCBA
  • LED Flashlight PCBALED Flashlight PCBA
  • LED Flashlight PCBALED Flashlight PCBA
  • LED Flashlight PCBALED Flashlight PCBA

LED Flashlight PCBA

Since 2008, Unixplore Electronics has been providing one-stop turnkey manufacture and supply services for high-quality LED flashlight PCBA in China. The company is certified with ISO9001:2015 and adheres to the PCB assembly standard of IPC-610E.

Send Inquiry

Product Description

What is LED Flashlight PCBA ?

We want to take this opportunity to introduce you to our high-quality LED flashlight PCBA at Unixplore Electronics. Our primary objective is to make sure that our customers fully comprehend the capabilities and features of our products. We are always eager to partner with our existing and new customers to foster a better future.
The LED flashlight control board is a circuit board specially used to control the LED flashlight. It can control the brightness and color of the LED lamp beads by controlling the output of the current, while having a protective circuit to ensure the safe use of LED lamp beads. The LED flashlight control board can be used with LED lamp beads, so that the flashlight has higher brightness and better service life.
Unixplore provides one-stop turnkey service for your EMS project. Feel free to contact us for your board building, we can make a quotation in 24 hours after we receive your Gerber file and BOM list!

LED Flashlight PCBA Manufacture

* Gerber file and BOM list supplied by client
* Blank PCB made, components purchased by us
* PCB fabrication with parts fully assembled
* 100% Function Tested OK before shipping
* RoHS compliant, Lead-free manufacturing process
* Quick delivery, with independent ESD package
* One stop electronic manufacturing service for PCB design, PCB layout, PCB manufacture, components procurement, PCB SMT and DIP assembly, IC programming, function test, packaging and delivery

Unixplore PCB & PCB Assembly Capability

Parameter Capability
Layers 1-40 layers
Assembly Type Through-Hole (THT), Surface Mount (SMT), Mixed (THT+SMT)
Minimum Component Size 0201(01005 Metric)
Maximum Component Size 2.0 in x 2.0 in x 0.4 in (50 mm x 50 mm x 10 mm)
Component Package Types BGA, FBGA, QFN, QFP, VQFN, SOIC, SOP, SSOP, TSSOP, PLCC, DIP, SIP, etc.
Minimum Pad Pitch 0.5 mm (20 mil) for QFP, QFN, 0.8 mm (32 mil) for BGA
Minimum Trace Width 0.10 mm (4 mil)
Minimum Trace Clearance 0.10 mm (4 mil)
Minimum Drill Size 0.15 mm (6 mil)
Maximum Board Size 18 in x 24 in (457 mm x 610 mm)
Board Thickness 0.0078 in (0.2 mm) to 0.236 in (6 mm)
Board Material CEM-3,FR-2,FR-4, High-Tg, HDI, Aluminum, High Frequency, FPC, Rigid-Flex, Rogers, etc.
Surface Finish OSP, HASL, Flash Gold, ENIG, Gold Finger, etc.
Solder Paste Type Leaded or Lead-Free
Copper Thickness 0.5OZ – 5 OZ
Assembly Process Reflow Soldering, Wave Soldering, Manual Soldering
Inspection Methods Automated Optical Inspection (AOI), X-ray, Visual Inspection
Testing Methods In-House Functional Test, Probe Test, Aging Test, High and Low Temperature Test
Turnaround Time Sampling: 24 hours to 7 days, Mass Run: 10 - 30 days
PCB Assembly Standards ISO9001:2015; ROHS, UL 94V0, IPC-610E class ll

Unixplore Value-Added EMS Service

● IC pre-programming service with file in format of HEX,ELF and BIN.
● LED Flashlight PCBA Function test fixture customized according to client’s test requirements
● Box building service including plastic & metal case mold and part production
● Conformal coating including selective lacquer coating, epoxy resin potting
● Wire harness and cable assembly
● Finished product assembly including box, screen, membrane switch, labelling and customized carton or retail box packing.
● Various third-party tests for PCBA are available upon request
● Product Certification Assistance

PCBA Production Procedure

  • LED Flashlight PCBA

    1. Automatic solderpaste printing

  • LED Flashlight PCBA

    2. solderpaste printing done

  • LED Flashlight PCBA

    3. SMT pick and place

  • LED Flashlight PCBA

    4. SMT pick and place done

  • LED Flashlight PCBA

    5. ready for reflow soldering

  • LED Flashlight PCBA

    6. reflow soldering done

  • LED Flashlight PCBA

    7. ready for AOI

  • LED Flashlight PCBA

    8. AOI inspection process

  • LED Flashlight PCBA

    9. THT component placement

  • LED Flashlight PCBA

    10. wave soldering process

  • LED Flashlight PCBA

    11. THT assembly done

  • LED Flashlight PCBA

    12. AOI Inspection for THT assembly

  • LED Flashlight PCBA

    13. IC programming

  • LED Flashlight PCBA

    14. function test

  • LED Flashlight PCBA

    15. QC Check and Repair

  • LED Flashlight PCBA

    16. PCBA conformal coating Process

  • LED Flashlight PCBA

    17. ESD packing

  • LED Flashlight PCBA

    18. Ready for Shipping


Packaging

For PCBA

LED Flashlight PCBA
LED Flashlight PCBA
For Finished Product

LED Flashlight PCBA
LED Flashlight PCBA
