Since 2008, Unixplore Electronics has been providing one-stop turnkey manufacture and supply services for high-quality electric sprayer PCBA in China,which is widely used in various electric sprayers and atomizers for domestic and commercial use. Our company is certified with ISO9001:2015 and adheres to the PCB assembly standard of IPC-610E.

Model:UE-140

Send Inquiry

Product Description


How to find a suitable factory for your electric sprayer PCBA project ?



We would like to take this opportunity to introduce you to the high quality Electric Sprayer PCBA from Unixplore Electronics. Our main goal is to ensure that our customers fully understand the functionality and features of our products. We are always eager to cooperate with existing and new customers to create a better future.




When choosing a suitable electric sprayer PCBA factory, you can consider the following aspects:


The experience and strength of the factory: Understand the factory's processing experience and strength in electric sprayer PCBA, and see whether it has a professional technical team and advanced equipment, and whether it has relevant certifications and qualifications.


Quality control system of the factory: Understand the quality management measures, production processes and quality inspection systems of the factory to ensure that the factory can produce high-quality electric sprayer PCBA as required.


Cost-effectiveness: When choosing a suitable factory, you must not only consider quality and production capacity, but also factors such as price and service, and choose a factory with a higher cost-effectiveness.


Other factors: such as the delivery time of the factory, after-sales service, cooperation methods, etc., also need to be taken into consideration.


In terms of finding factory, you can screen out by participating in industry exhibitions, searching on the Internet, consulting people in the industry, etc. After understanding the basic situation of the factory, conduct in-depth exchanges and negotiations to choose the most suitable one.



Unixplore provides one-stop turn-key service for your Contract Electronic Manufacturing project. Feel free to contact us for your circuit board assembly building, we can make a quotation in 24 hours after we receive your Gerber file and BOM list!


Electric Sprayer PCBA Manufacture

* Gerber file and BOM list supplied by client
* Bare PCB produced, components purchased by us
* PCB fabrication with parts fully assembled
* 100% Functional test OK before shipping
* RoHS compliant, Lead-free manufacturing process
* Quick delivery, with independent ESD package
* One stop electronic manufacturing service for PCB design, PCB layout, PCB manufacture, components procurement, PCB SMT and THT assembly, IC programming, function test, packaging and delivery

Unixplore PCB & PCB Assembly Capability

Parameter Capability
Layers 1-40 layers
Assembly Type Through-Hole (THT), Surface Mount (SMT), Mixed (THT+SMT)
Minimum Component Size 0201(01005 Metric)
Maximum Component Size 2.0 in x 2.0 in x 0.4 in (50 mm x 50 mm x 10 mm)
Component Package Types BGA, FBGA, QFN, QFP, VQFN, SOIC, SOP, SSOP, TSSOP, PLCC, DIP, SIP, etc.
Minimum Pad Pitch 0.5 mm (20 mil) for QFP, QFN, 0.8 mm (32 mil) for BGA
Minimum Trace Width 0.10 mm (4 mil)
Minimum Trace Clearance 0.10 mm (4 mil)
Minimum Drill Size 0.15 mm (6 mil)
Maximum Board Size 18 in x 24 in (457 mm x 610 mm)
Board Thickness 0.0078 in (0.2 mm) to 0.236 in (6 mm)
Board Material CEM-3,FR-2,FR-4, High-Tg, HDI, Aluminum, High Frequency, FPC, Rigid-Flex, Rogers, etc.
Surface Finish OSP, HASL, Flash Gold, ENIG, Gold Finger, etc.
Solder Paste Type Leaded or Lead-Free
Copper Thickness 0.5OZ – 5 OZ
Assembly Process Reflow Soldering, Wave Soldering, Manual Soldering
Inspection Methods Automated Optical Inspection (AOI), X-ray, Visual Inspection
Testing Methods In-House Functional Test, Probe Test, Aging Test, High and Low Temperature Test
Turnaround Time Sampling: 24 hours to 7 days, Mass Run: 10 - 30 days
PCB Assembly Standards ISO9001:2015; ROHS, UL 94V0, IPC-610E class ll

Unixplore Value-Added Electronic Manufacturing Service

● IC pre-programming service with file in format of HEX,ELF and BIN.
● Electric Sprayer PCBA Function test fixture customized according to client’s test requirements
● Box building service including plastic & metal case mold and part production
● Conformal coating including selective lacquer coating, epoxy resin potting
● Wire harness and cable assembly
● Finished product assembly including box, screen, membrane switch, labelling and customized carton or retail box packing.
● Various third-party tests for PCBA are available upon request
● Product Certification Assistance

PCBA Production Procedure

  • Electric Sprayer PCBA

    1. Automatic solderpaste printing

  • Electric Sprayer PCBA

    2. solderpaste printing done

  • Electric Sprayer PCBA

    3. SMT pick and place

  • Electric Sprayer PCBA

    4. SMT pick and place done

  • Electric Sprayer PCBA

    5. ready for reflow soldering

  • Electric Sprayer PCBA

    6. reflow soldering done

  • Electric Sprayer PCBA

    7. ready for AOI

  • Electric Sprayer PCBA

    8. AOI inspection process

  • Electric Sprayer PCBA

    9. THT component placement

  • Electric Sprayer PCBA

    10. wave soldering process

  • Electric Sprayer PCBA

    11. THT assembly done

  • Electric Sprayer PCBA

    12. AOI Inspection for THT assembly

  • Electric Sprayer PCBA

    13. IC programming

  • Electric Sprayer PCBA

    14. function test

  • Electric Sprayer PCBA

    15. QC Check and Repair

  • Electric Sprayer PCBA

    16. PCBA conformal coating Process

  • Electric Sprayer PCBA

    17. ESD packing

  • Electric Sprayer PCBA

    18. Ready for Shipping


Packaging

For PCBA

Electric Sprayer PCBA
Electric Sprayer PCBA
For Finished Product

Electric Sprayer PCBA
Electric Sprayer PCBA
